Murrelektronik
M12 Power female 0° K-cod. with cable
Price excluding VAT
Request a quote
USA Power Female straight M12, 5-pole K-coded Plastic housings with good resistance against chemicals and oils. The resistance to aggressive media should be...
Weight
1,691 kg
Country of origin
DE
Model designation
MSWBKL0-UU9P_7.5
Cable length
7,5 m
Tightening torque
0,6 Nm
Mounting method
inserted, screwed, Shaking protection
Coating contact
gold plated
Family construction form
free cable end
Thread
M12 x 1
suitable for corrugated tube (internal Ø)
16,4 mm
Cable outlet
straight
Coding
K
Material contact
Copper alloy
Material
PUR
No. of poles
5
