Murrelektronik
M12 male duo 0° A-cod. screw terminal
Hind käibemaksuta
Küsi pakkumist
Male straight Y-connector M12, 5-pole Screw terminals Sealing range (cable Ø): 2.1...3/4...5 mm Plastic housings with good resistance against chemicals and...
Kaal
0,025 kg
Päritoluriik
HU
Mudeli tähistus
MSA-U11D
Family construction form
M12
No. of poles
5
Coding
A
Material contact
Brass
Degree of protection (EN IEC 60529)
IP67
Operating voltage AC max.
60 V
Operating voltage DC max.
60 V
Current operating per contact max.
4 A
Connection cross section max.
0,75 mm²
Width across flats
SW18
Additional condition protection degree
inserted, screwed
Pollution Degree
3
