Murrelektronik
M12 male 0° / MSUD valve plug A-18mm V2A
Hind käibemaksuta
Küsi pakkumist
MSUD Form A (18 mm) – M12, male straight 24 V AC ±20% / DC ±25% LED and suppression Stainless steel 1.4305 (V2A) Further cable lengths on request....
Kaal
0,105 kg
Päritoluriik
CZ
Mudeli tähistus
MSKL3-A-W216_0.3-S02
Cable length
0,30 m
Family construction form
Valve connector form A
No. of poles
4
Coding
A
Mounting method
inserted, screwed
Threaded hole
M3x31
Tightening torque
0,4 Nm
Width across flats
SW13
suitable for corrugated tube (internal Ø)
10 mm
Material
PUR
Material contact
Copper alloy
Coating contact
gold plated
