Male straight – female straight M12 – M8, 3-pole USA Plastic housings with good resistance against chemicals and oils. The resistance to aggressive media...
Вес
0,025 kg
Страна происхождения
DE
Обозначение модели
MSFL0-A-RU03_0.3
Cable length
0,30 m
Family construction form
M8
No. of poles
3
Coding
A
Mounting method
inserted, screwed, Shaking protection
Threaded hole
M8 x 1
Tightening torque
0,4 Nm
Width across flats
SW9
Cable outlet
straight
suitable for corrugated tube (internal Ø)
8,5 mm
Operating voltage AC max.
50 V
Operating voltage DC max.
60 V
