Customized printing and packaging Male straight – female 90° M12 – M12, 3-pole with cable sleeves Zinc die casting, save-cover coated Plastic housings...
Kaal
0,082 kg
Päritoluriik
DE
Mudeli tähistus
MSDL0-A-R653_2.0-DS-XH-S36
Cable length
2,00 m
Family construction form
M12
No. of poles
3
Coding
A
Gender
female
Mounting method
inserted, screwed, Shaking protection
Threaded hole
M12 x 1
Tightening torque
0,6 Nm
Width across flats
SW13
Cable outlet
angled
suitable for corrugated tube (internal Ø)
10 mm
Material contact
Copper alloy
