Customized printing and packaging Male straight – female straight M12 – M12, 4-pole Shielded with cable sleeves Plastic housings with good resistance...
Kaal
0,590 kg
Päritoluriik
DE
Mudeli tähistus
MSBL0-A-T639_10.0-XH-ZE
Cable length
10,00 m
Family construction form
M12
No. of poles
4
Mounting method
inserted, screwed
Threaded hole
M12 x 1
Tightening torque
0,6 Nm
Width across flats
SW13
Material contact
Copper alloy
Coating contact
gold plated
Degree of protection (EN IEC 60529)
IP67, IP65
Operating voltage AC max.
60 V
Operating voltage DC max.
60 V
