Male straight – female straight M12 – M12, 3-pole C-coded Plastic housings with good resistance against chemicals and oils. The resistance to aggressive...
Вес
0,037 kg
Страна происхождения
DE
Обозначение модели
MSEBL0-EA-9626_0.6-S23
Cable length
0,60 m
Family construction form
M12
No. of poles
3
Coding
C
Mounting method
inserted, screwed, Shaking protection
Threaded hole
M12 x 1
Tightening torque
0,6 Nm
Width across flats
SW13
suitable for corrugated tube (internal Ø)
10 mm
Material contact
Copper alloy
Coating contact
gold plated
Operating voltage AC max.
250 V
