Customized printing and packaging Male straight M12, 4-pole Screw terminals Sealing range (cable Ø): 4...6 mm Plastic housings with good resistance against...
Вес
0,023 kg
Страна происхождения
DE
Обозначение модели
MSAL0-T-SK 4..6mm
Family construction form
M12
No. of poles
4
Coding
A
Material contact
Copper alloy
Degree of protection (EN IEC 60529)
IP67
Operating voltage AC max.
250 V
Operating voltage DC max.
250 V
Current operating per contact max.
4 A
Current operating per contact max. (URc.)
3 A
Status indication LED
No
Connection cross section max.
0,75 mm²
Tightening torque
0,6 Nm
