Male straight M12, 5-pole B-coded Art-No. 7005 - M12 Lite - (plastic hexagonal screw) on request Plastic housings with good resistance against chemicals and...
Weight
0,033 kg
Country of origin
DE
Model designation
MSBAL0-U235_0.5-KV
Cable length
0,50 m
Family construction form
free cable end
No. of poles
5
Coding
B
Mounting method
inserted, screwed, Shaking protection
Threaded hole
M12 x 1
Tightening torque
0,6 Nm
Width across flats
SW13
Cable outlet
straight
suitable for corrugated tube (internal Ø)
10 mm
Material
PUR
Material contact
Copper alloy
