Customized printing and packaging Female straight M12, 5-pole Screw terminal Connection cross section max. 0.75 mm² Please use wire end ferrule. The...
Kaal
0,023 kg
Päritoluriik
DE
Mudeli tähistus
MSBL0-U-SK 6..8mm
Family construction form
M12
No. of poles
5
Coding
A
suitable for corrugated tube (internal Ø)
8 mm
Material contact
Copper alloy
Degree of protection (EN IEC 60529)
IP67
Operating voltage AC max.
60 V
Operating voltage DC max.
60 V
Current operating per contact max.
4 A
Current operating per contact max. (URc.)
3 A
Connection cross section max.
0,75 mm²
Tightening torque
0,6 Nm
