Murrelektronik
IMPACT67 PN DO16 M12L 4P galvanic separation
Prix hors TVA
Demander un devis
Digital outputs DO16 (IRT) Ethernet 10/100 Mbit/s; M12, D-coded M12 power, 4-pin, L-coded, 2× max. 12 A M12, 5-pole, A-coded Fast-Start-Up (FSU) Galvanic...
Poids
0,486 kg
Pays d'origine
DE
Désignation du modèle
IMPACT67 PN DO16 M12L 4P
Norm operating voltage
IEC/EN 61131-2
Total current US max.
12 A
Operating voltage UA DC
24 V
Total current UA max.
12 A
Output current per pin max.
2 A
Overload resistant
Yes
Short-circuit protected
Yes
Supported protocol
Profinet
Conformance Class
C
addressing
DCP
Netload Class
III
Specification
V2.3
