Üksikasjalik kirjeldus puudub.
Reading field
Side
Optical focus
Variable (through exchangeable lens)
Sensor
CMOS Mono
Sensor resolution
2,048 px x 1,944 px (4 megapixel)
Light source
External illumination
Lens
C-mount
Reading distance
100 mm ... 3,000 mm1)2)
Scanning frequency
10 Hz, at full resolution
Code resolution
≥ 0.1 mm1)
Connection type
1 x M12 cylindrical connector (4-pin female connector, Ethernet)1
Supply voltage
15 V DC ... 30 V DC
Power consumption
8 W
Housing material
Die-cast zinc
Housing color
Light blue (RAL 5012)
Enclosure rating
IP65 (EN 60529)1)IP302)
Protection class
III (EN 61140)
Kaal
900 g, with connecting cable
Dimensions (L x W x H)
123.3 mm x 80 mm x 39 mm
MTBF
75,000 h
Bar code types
GS1-128 / EAN 128, UPC / GTIN / EAN, Interleaved 2 of 5, Pharmacode, Code 39, Code 128, Codabar
2D code types
Data Matrix ECC200, GS1 Data-Matrix, QR code
No. of codes per scan
1 ... 50
No. of codes per reading interval
1 ... 50
No. of characters per reading interval
4,000
Digital inputs
2
Digital outputs
2 (Result 1 NPN, Result 2 PNP)
Reading pulse
Switching inputs, non-powered, serial interface
Optical indicators
6 LEDs (status displays)
Acoustic indicators
Beeper/buzzer (can be switched off, can be assigned a function to signal a result)
Electromagnetic compatibility (EMC)
EN 61000-6-2 / EN 61000-6-4
Vibration resistance
EN 60068-2-6
Shock resistance
EN 60068-2-27
Ambient operating temperature
0 °C ... +40 °C
Storage temperature
–20 °C ... +70 °C
Permissible relative humidity
± 90 %, Non-condensing
Ambient light immunity
2,000 lx, on barcode
Life cycle phase
Discontinued
Items supplied
Single scanner
ECLASS 5.0
27280103
ECLASS 5.1.4
27280103
ECLASS 6.0
27280103
ECLASS 6.2
27280103
ECLASS 7.0
27280103
ECLASS 8.0
27280103
ECLASS 8.1
27280103
ECLASS 9.0
27280103
ECLASS 10.0
27280103
ECLASS 11.0
27280103
ECLASS 12.0
27280103
ETIM 5.0
EC002550
ETIM 6.0
EC002550
ETIM 7.0
EC002999
ETIM 8.0
EC002999
UNSPSC 16.0901
43211701
