Murrelektronik
h-coupler MQ15 male - fem. 0° / fem. 0° 600V AC
Hind käibemaksuta
Küsi pakkumist
Male straight – female straight MQ15, 4-pole partly used with cable sleeves S1: MQ15 male, S2: MQ15 female with cable P72, S3: MQ15 female with cable P71...
Kaal
1,038 kg
Päritoluriik
DE
Mudeli tähistus
MSWAQ3Y6P7-WBQ36P7P72_5.0-WBQ36P7P71_2.5
Cable length
2,5 m
Family construction form
MQ15
No. of poles
4
Coding
Type 3
Gender
female
Mounting method
locked, inserted
Cable outlet
straight
Degree of protection (EN IEC 60529)
IP67, IP65
suitable for corrugated tube (internal Ø)
18 mm
Operating voltage AC max.
600 V
Status indication LED
No
Configuration
partly used
