Female 2-pole Axial screw connection Technical data will be only guaranteed with Murrelektronik components. Axial screw connection only for flexible wires...
Вес
0,032 kg
Страна происхождения
PL
Обозначение модели
MSMH-MBUM-1M-A-2pol. 1000 V 70 A
Operating voltage AC
1.000 V
Operating voltage DC
1.000 V
Operating current
70 A
Connection cross section min.
6 mm²
Connection cross section max.
25 mm²
AWG number min.
9
AWG number max.
3
Gender
female
Tightening torque
(6 mm²); 3 Nm (10...25 mm²)
Width across flats
SW2.5
Mating cycles min.
500
Stripping length min.
11 mm
