Murrelektronik
EXACT8, 8XM8, 3 POLE PRE-WIRED CABLE
Prix hors TVA
Demander un devis
8-way, 3-pole Further cable lengths on request. Plastic housings with good resistance against chemicals and oils. The resistance to aggressive media should...
Poids
0,688 kg
Pays d'origine
DE
Désignation du modèle
MVP8N-AN8D357 5.0M
Operating voltage DC
24 V
Current operating per contact max.
2 A
Total current max.
8 A
Number of signals per port
1
Mounting set
M8 x 1
Degree of protection (EN IEC 60529)
IP67, IP65
Flame resistance
UL 1581 § 1090, CSA FT2, IEC 60332-2-2
Material housing
Plastic
Mounting method
Schraubgewinde
Operating temperature min.
-20 °C
Operating temperature max.
80 °C
Additional condition temperature range
depending on cable quality
