Murrelektronik
EXACT12, 8XM12, 5-POLE, CAP, PLUG. SCREW TERM.
Price excluding VAT
Request a quote
8-way, 5-pole without LED, up to 125 V AC/DC Screw plug-in terminals Plastic housings with good resistance against chemicals and oils. The resistance to...
Weight
0,204 kg
Country of origin
DE
Model designation
MVP12N-FN8F-XA
Operating voltage AC
125 V
Operating voltage DC
125 V
Current operating per contact max.
4 A
Total current max.
8 A
Connection cross section max.
1,5 mm²
AWG number max.
16
Connection
Screw plug-in terminals
Degree of protection (EN IEC 60529)
IP67, IP65
Flame resistance
flame retardant
Material housing
Plastic
Operating temperature min.
-20 °C
Operating temperature max.
70 °C
