Murrelektronik
Cube67 I/O Cable-Module, I/O Extension Module
Price excluding VAT
Request a quote
Expansion module DO7 - 0.5 A (E) 0.5 m (M12) for Modlight70 Pro basic Connection cables are in the online shop under "Connection Technology". Housing fully...
Weight
0,260 kg
Country of origin
CZ
Model designation
Cube67 DO7 E Cable M12 Modlight
Norm operating voltage
IEC/EN 61131-2
Total current US max.
4 A
Operating voltage UA DC
24 V
Total current UA max.
4 A
Current consumption max.
50 mA
Output current per pin max.
0,5 A
Overload resistant
Yes
Short-circuit protected
Yes
Actuator warning
per channel via BUS
Short circuit diagnosis
Yes
Overload diagnosis
Yes
Diagnostic
No voltage, Under voltage
