PUR/PVC 5× 1.0 mm²
Weight
5,907 kg
Country of origin
IT
Model designation
50m Kabel 10080532(965) BUND
Note on bending radius
Attention: Observe the permissible bending radii when laying cables, as the IP protection class can be endangered by excessive bending forces.
Note on strain relief
Protect the connectors by suitable measures from mechanical loads, e.g. by the usage of cable ties.
Cable identification
965
Amount stranding
1
Stranding
Wires
Filler
Yes
Cable weigth
79 g/m
Material wire insulation
PP
Amount wires
5
Outer diameter insulation
2 mm
Outer diameter tolerance core insulation
± 0,1 mm
Shore hardness wire insulation
60 ± 5 Shore D
