BSP0003 (BSP B050-DV001-I01A0A-S4) - Pressure transmitter - Measuring range: 0...50 bar, Accuracy: ±0.5 % FSO BFSL, Overload pressure: 75 bar, Burst pressure: 100.00 bar, Operating voltage Ub: 15...32 VDC, Connection: Connector, M12x1-Male, 4-pin, Process connection: G 1/4", Gasket, material: FKM, Housing material: Stainless steel (1.4301), Media temperature: -25...100 °C, Ambient temperature: -25...70 °C, IP rating: IP67, when threaded in, Approval/Conformity: CE, cULus, WEEE
Measuring range
0...50 bar
Accuracy
±0.5 % FSO BFSL
Overload pressure
75 bar
Burst pressure
100.00 bar
Operating voltage Ub
15...32 VDC
Connection
Connector, M12x1-Male, 4-pin
Process connection
G 1/4"
Gasket, material
FKM
Housing material
Stainless steel (1.4301)
Media temperature
-25...100 °C
Ambient temperature
-25...70 °C
IP rating
IP67, when threaded in
Approval/Conformity
CEcULusWEEE
Manufacturer
Balluff GmbH
Tariff Code
90262020
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
