BOS R080K-XM-RS10-00,3-S4

BOS028K (BOS R080K-XM-RS10-00,3-S4) - Through-beam sensors - List price Deutschland: 149,35 EUR - Special characteristics: Washdown Plus, Washdown, Series: R080K, Dimension: 19 x 44.1 x 37.5 mm, Interface: IO-Link: 1.1, Analog, current: 4…20 mA, Pin 4: Push-pull: NO/NC, Pin 2: PNP/NPN/push-pull: NO/NC, Principle of operation: Photoelectric sensor, Principle of optical operation: Through-beam sensor (Emitter), Light type: LED, red light, Range: 0...20 m, Connection: Cable with connector, M12x1-Male, 4-pin, 300 mm, PVC, Housing material: PA 12, PA PACM 12, Material sensing surface: PA PACM 12, Operating voltage Ub: 10...30 VDC, Approval/Conformity: CE, UKCA, WEEE, cULus, Ecolab, Scope of delivery: Mounting instruction
