Balluff
BOS Q08M-PS-KE20-00,2-S49
Recommended replacement:
Price excluding VAT
Request a quote
BOS00YC (BOS Q08M-PS-KE20-00,2-S49) - Through-beam sensors - Series: Q08M, Dimension: 8 x 44 x 8 mm, Interface: PNP normally open (NO), Principle of operation: Photoelectric sensor, Principle of optical operation: Through-beam sensor (receiver), Light type: Red light, Range: 0...2.2 m, Connection: Cable with connector, M8x1-Male, 3-pin, 0.20 m, PUR, Housing material: Zinc, Die casting, nickel-plated, Material sensing surface: PMMA, Operating voltage Ub: 10...30 VDC, Approval/Conformity: cULus, CE, UKCA, WEEE
Series
Q08M
Interface
PNP normally open (NO)
Principle of operation
Photoelectric sensor
Principle of optical operation
Through-beam sensor (receiver)
Light type
Red light
Range
0...2.2 m
Connection
Cable with connector, M8x1-Male, 3-pin, 0.20 m, PUR
Housing material
Zinc, Die casting, nickel-plated
Material sensing surface
PMMA
Operating voltage Ub
10...30 VDC
Approval/Conformity
cULusCEUKCAWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity | (All languages)
Tariff Code
85365019
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
