BNS0363 (BNS 819-X748-D04-D12-100-55-FD) - Multiple position: Special - List price Deutschland: 922,42 EUR - Housing material: Aluminium, Anodized, Version: Snap contact, Operating principle: 1-3. Switch position: Inductive, 4. Switch position: Mechanical, Range: 2 mm, Continuous current: 1-3. Switch position: 0.2 A, 4. Switch position: 6 A, Rated operating voltage Ue: 1-3. Switch position: 24 V DC, 4. Switch position: 30 V AC/36 V DC, Installation: Vertical, Approach direction: longitudinal, parallel to attachment surface, Approach speed: 4. Switch position: 40 m/min, Ambient temperature: -5...70 °C, IP rating: IP67, Approval/Conformity: CE, UKCA, WEEE
Housing material
Aluminium, Anodized
Version
Snap contact
Operating principle
1-3. Switch position: Inductive | 4. Switch position: Mechanical
Range
2 mm
Continuous current
1-3. Switch position: 0.2 A | 4. Switch position: 6 A
Rated operating voltage Ue
1-3. Switch position: 24 V DC4. Switch position: 30 V AC/36 V DC
Installation
Vertical
Approach direction
longitudinal, parallel to attachment surface
Approach speed
4. Switch position: 40 m/min
Ambient temperature
-5...70 °C
IP rating
IP67
Approval/Conformity
CEUKCAWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity | (All languages)
Tariff Code
85365080
Substances of concern
Download
Disposal instructions
Download
Juhendid, CAD-mudelid, sertifikaadid ja muud materjalid on tootja veebisaidil:
Ava toote leht tootja veebisaidil
