BNS04HP (BNS 819-D12-R16-100-10-FE-S90S) - Mechanical multiple position limit switches - Housing material: Aluminium, Anodized, Number of switching positions: 5x Roller, Version: Snap contact, Operating principle: 1-12. Switch position: Mechanical, Continuous current: 1-12. Switch position: 5 A, Rated operating voltage Ue: 1-3. Switch position: 6…60 V, 4. Switch position: 30 V AC/36 V DC, 5-12. Switch position: 6…60 V, Installation: Vertical, Approach direction: longitudinal, parallel to attachment surface, Approach speed: 1-12. Switch position: 60 m/min, Ambient temperature: -5...85 °C, IP rating: IP67, Approval/Conformity: CE, WEEE
Housing material
Aluminium, Anodized
Number of switching positions
5x Roller
Version
Snap contact
Operating principle
1-12. Switch position: Mechanical
Continuous current
1-12. Switch position: 5 A
Rated operating voltage Ue
1-3. Switch position: 6…60 V4. Switch position: 30 V AC/36 V DC5-12. Switch position: 6…60 V
Installation
Vertical
Approach direction
longitudinal, parallel to attachment surface
Approach speed
1-12. Switch position: 60 m/min
Ambient temperature
-5...85 °C
IP rating
IP67
Approval/Conformity
CEWEEE
Manufacturer
Balluff GmbH
Manual
BNS Z/INSTALL-SHEET | (English)
Tariff Code
85371091
Disposal instructions
Download
