BNS00HF (BNS 819-D04-E12-100-14-DH) - Mechanical multiple position limit switches - List price Deutschland: 923,50 EUR - Housing material: Aluminium, Anodized, Number of switching positions: 4x E-Chisel, Version: mechanical-inductive, Operating principle: 1-4. Switch position: mechanical-inductive, Rated operating voltage Ue: 1-4. Switch position: 24 V DC, Installation: Vertical, Approach direction: longitudinal, parallel to attachment surface, Approach speed: 1-4. Switch position: 30 m/min, Connection type: 1-4. Switch position: Screw terminal, Ambient temperature: -5...70 °C, IP rating: IP67, Approval/Conformity: CE, UKCA, WEEE
Housing material
Aluminium, Anodized
Number of switching positions
4x E-Chisel
Version
mechanical-inductive
Operating principle
1-4. Switch position: mechanical-inductive
Rated operating voltage Ue
1-4. Switch position: 24 V DC
Installation
Vertical
Approach direction
longitudinal, parallel to attachment surface
Approach speed
1-4. Switch position: 30 m/min
Connection type
1-4. Switch position: Screw terminal
Ambient temperature
-5...70 °C
IP rating
IP67
Approval/Conformity
CEUKCAWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity | (All languages)
Tariff Code
85365080
Substances of concern
Download
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
