BNS053Y (BNS 819-100-D-12-FC-S80) - Mechanical single position limit switches - Housing material: Aluminium, Anodized, Version: Snap contact, Operating principle: 1. Switch position: Mechanical, Continuous current: 1. Switch position: 0.1 A, Rated operating voltage Ue: 1. Switch position: 24 V DC, Installation: any, Approach direction: lateral or at right angles to mounting surface, Approach speed: 1. Switch position: 20 m/min, Connection type: 1. Switch position: Connector, Ambient temperature: -5...85 °C, IP rating: IP67, Approval/Conformity: CE, UKCA, WEEE
Housing material
Aluminium, Anodized
Version
Snap contact
Operating principle
1. Switch position: Mechanical
Continuous current
1. Switch position: 0.1 A
Rated operating voltage Ue
1. Switch position: 24 V DC
Installation
any
Approach direction
lateral or at right angles to mounting surface
Approach speed
1. Switch position: 20 m/min
Connection type
1. Switch position: Connector
Ambient temperature
-5...85 °C
IP rating
IP67
Approval/Conformity
CEUKCAWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Manual
BNS 99/100 819/813 | (German, English)
Tariff Code
85365080
Disposal instructions
Download
