BNS03ZH (BNS 816-B06-EJA-16-605-11) - Inductive multiple position limit switches - Housing material: Aluminum, Anodized, Version: Inductive, Operating principle: 1-6. Switch position: Inductive, Range: 5 mm, Switching frequency: 1-6. Switch position: 500 Hz, Continuous current: 1-6. Switch position: 0.1 A, Rated operating voltage Ue: 1-6. Switch position: 220 V AC, Installation: parallel, Connection type: 1-6. Switch position: Screw terminal, Ambient temperature: -25...70 °C, IP rating: IP67, Approval/Conformity: CE, CCC, WEEE
Housing material
Aluminum, Anodized
Version
Inductive
Operating principle
1-6. Switch position: Inductive
Range
5 mm
Switching frequency
1-6. Switch position: 500 Hz
Continuous current
1-6. Switch position: 0.1 A
Rated operating voltage Ue
1-6. Switch position: 220 V AC
Installation
parallel
Connection type
1-6. Switch position: Screw terminal
Ambient temperature
-25...70 °C
IP rating
IP67
Approval/Conformity
CECCCWEEE
Manufacturer
Balluff GmbH
Tariff Code
85371098
