BNS0389 (BNS 816-B02-NA-12-602-11) - Inductive multiple position limit switches - Housing material: Aluminium, Anodized, Version: Inductive, Operating principle: 1-2. Switch position: Inductive, Range: 2 mm, Switching frequency: 1-2. Switch position: 1500 Hz, Continuous current: 1-2. Switch position: 0.2 A, Rated operating voltage Ue: 1-2. Switch position: 24 V DC, Installation: Vertical, Connection type: 1-2. Switch position: Screw terminal, Ambient temperature: -25...70 °C, IP rating: IP67, Approval/Conformity: CE, CCC, WEEE
Housing material
Aluminium, Anodized
Version
Inductive
Operating principle
1-2. Switch position: Inductive
Range
2 mm
Switching frequency
1-2. Switch position: 1500 Hz
Continuous current
1-2. Switch position: 0.2 A
Rated operating voltage Ue
1-2. Switch position: 24 V DC
Installation
Vertical
Connection type
1-2. Switch position: Screw terminal
Ambient temperature
-25...70 °C
IP rating
IP67
Approval/Conformity
CECCCWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Tariff Code
85371098
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
