BNS 813-B06-D12-72-55-0678

BNS048K (BNS 813-B06-D12-72-55-0678) - Mechanical multiple position limit switches with safety switch positions - Housing material: Aluminium, Anodized, Number of switching positions: 6x Chisel, Version: Safety EN 60204-1, Operating principle: 1. Switch position: Mechanical, 2-6. Switch position: Inductive, Continuous current: 1. Switch position: 6 A, 2-6. Switch position: 0.13 A, Rated operating voltage Ue: 1. Switch position: 250 V AC, 2-6. Switch position: 24 V DC, Installation: Horizontal, Approach direction: Vertical to mounting surface, Approach speed: 1. Switch position: 12 m/min, Connection type: 1-6. Switch position: Screw terminal, Ambient temperature: -5...70 °C, IP rating: IP67, Approval/Conformity: CE, WEEE
