BNS03UN (BNS 813-B02-R08-46-49-02-FC-S80R) - Mechanical multiple position limit switches with positive opening - Housing material: Aluminium, Anodized, Number of switching positions: 2x Roller, Version: with forced opening, Operating principle: 1-2. Switch position: Mechanical, Continuous current: 1-2. Switch position: 4 A, Rated operating voltage Ue: 1-2. Switch position: 24 V DC, Installation: Vertical, Approach direction: longitudinal, parallel to attachment surface, Approach speed: 1-2. Switch position: 60 m/min, Connection type: 1. Switch position: Connector, Ambient temperature: -5...85 °C, IP rating: IP67, Approval/Conformity: CE, CCC, WEEE
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
