BNS03TM (BNS 813-99-K-49) - Mechanical single position limit switches with positive opening - Housing material: Aluminium, Anodized, Number of switching positions: 1x Ball, Version: with forced opening, Operating principle: 1. Switch position: Mechanical, Continuous current: 1. Switch position: 5 A, Rated operating voltage Ue: 1. Switch position: 250 V AC, Installation: any, Approach direction: longitudinal, parallel to attachment surface, Approach speed: 1. Switch position: 9 m/min, Connection type: 1. Switch position: Screw terminal, Ambient temperature: -5...80 °C, IP rating: IP67, Approval/Conformity: CE, CCC, WEEE
Housing material
Aluminium, Anodized
Number of switching positions
1x Ball
Version
with forced opening
Operating principle
1. Switch position: Mechanical
Continuous current
1. Switch position: 5 A
Rated operating voltage Ue
1. Switch position: 250 V AC
Installation
any
Approach direction
longitudinal, parallel to attachment surface
Approach speed
1. Switch position: 9 m/min
Connection type
1. Switch position: Screw terminal
Ambient temperature
-5...80 °C
IP rating
IP67
Approval/Conformity
CECCCWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Tariff Code
85365080
Disposal instructions
Download
