Balluff
BLE 15K-S-F5-02
Remplacement recommandé:
Prix hors TVA
Demander un devis
BOS00C0 (BLE 15K-S-F5-02) - Through-beam sensors - Series: 15K, Dimension: 13 x 28 x 52 mm, Interface: PNP/NPN normally open/normally closed (NO/NC), Input function: Light-on/dark-on, Switching output PNP/NPN, Principle of operation: Photoelectric sensor, Principle of optical operation: Through-beam sensor (receiver), Light type: Infrared, Range: 0...5 m, Connection: Cable, 2.00 m, PVC, Housing material: ABS, Material sensing surface: PMMA, Operating voltage Ub: 10...30 VDC, Approval/Conformity: CE, WEEE
Series
15K
Interface
PNP/NPN normally open/normally closed (NO/NC)
Input function
Light-on/dark-on | Switching output PNP/NPN
Principle of operation
Photoelectric sensor
Principle of optical operation
Through-beam sensor (receiver)
Light type
Infrared
Range
0...5 m
Connection
Cable, 2.00 m, PVC
Housing material
ABS
Material sensing surface
PMMA
Operating voltage Ub
10...30 VDC
Approval/Conformity
CEWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Tariff Code
90314990
