BIC004A (BIC 2I2-V1A18-R01K01-SM3A30) - Inductive couplers for signal transmission - Function: Signal transmission, Signal type: unidirectional, Analog inputs: 4x Analog, voltage (0…10.65 V), Transmission distance: 1...3 mm, Component: Remote, Connection: Connector, M8x1, 3-pin, Output voltage: 24 VDC, Rated output current: 180 mA, Housing material: PET, Ambient temperature: 0...70 °C, IP rating: IP67
Function
Signal transmission
Signal type
unidirectional
Analog inputs
4x Analog, voltage (0…10.65 V)
Transmission distance
1...3 mm
Component
Remote
Connection
Connector, M8x1, 3-pin
Output voltage
24 VDC
Rated output current
180 mA
Housing material
PET
Ambient temperature
0...70 °C
IP rating
IP67
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Short guide
BIC UNI RADIAL ANALOG | (German)
Tariff Code
85176200
