BIC006U (BIC 2H0-X22A0-Q90AA-GPS04-020-Z15) - Inductive couplers for signal transmission - Signal type: unidirectional, Transmission distance: 6...8 mm, Component: Remote, Connection: Connector, 7/8", 5-pin, 2.00 m, PUR, Output voltage: 24 VDC, Rated output current: 2000 mA, Housing material: Aluminium, Dimension: 90 x 90 x 45 mm, Ambient temperature: 0...50 °C, IP rating: IP67
Signal type
unidirectional
Transmission distance
6...8 mm
Component
Remote
Connection
Connector, 7/8", 5-pin, 2.00 m, PUR
Output voltage
24 VDC
Rated output current
2000 mA
Housing material
Aluminium
Ambient temperature
0...50 °C
IP rating
IP67
Manufacturer
Balluff GmbH
Tariff Code
85176200
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
