BCS003R (BCS M12VVG1-NOM40C-EP02) - Capacitive proximity switches for object detection - Installation: for flush mounting, Connection: Cable, 2.00 m, PUR, Switching output: NPN normally closed (NC), Switching frequency: 100 Hz, Range: 1...4 mm, Housing material: PVC, Material sensing surface: PVC, Ambient temperature: -30...60 °C, Operating voltage Ub: 12...35 VDC, Approval/Conformity: CE, cULus, IP rating: IP65
Installation
for flush mounting
Connection
Cable, 2.00 m, PUR
Switching output
NPN normally closed (NC)
Switching frequency
100 Hz
Range
1...4 mm
Housing material
PVC
Material sensing surface
PVC
Ambient temperature
-30...60 °C
Operating voltage Ub
12...35 VDC
Approval/Conformity
CEcULus
IP rating
IP65
Manufacturer
Balluff GmbH
Manual
BCS STANDARD | (German)
Taric code
85365019
