BCS0050 (BCS G34VVM2-NPM20C-S04G) - Capacitive proximity switches for object detection - Installation: for flush mounting, Connection: Connector, M12x1-Male, 4-pin, Switching output: NPN NO/NC programmable, Switching frequency: 100 Hz, Range: 1...25 mm, Sensitivity: Switching distance adjustable, Housing material: PVC, Material sensing surface: PVC, Ambient temperature: -30...60 °C, Operating voltage Ub: 10...35 VDC, Approval/Conformity: CE, cULus, IP rating: IP66
Installation
for flush mounting
Connection
Connector, M12x1-Male, 4-pin
Switching output
NPN NO/NC programmable
Switching frequency
100 Hz
Range
1...25 mm
Sensitivity
Switching distance adjustable
Housing material
PVC
Material sensing surface
PVC
Ambient temperature
-30...60 °C
Operating voltage Ub
10...35 VDC
Approval/Conformity
CEcULus
IP rating
IP66
Manufacturer
Balluff GmbH
Manual
BCS STANDARD | (German)
Taric code
85365019
