BCS003J (BCS D22T403-NSM60C-EP02) - Capacitive proximity switches for object detection - Dimension: Ø 22 x 4 mm, Series: D22, Installation: for flush mounting, Connection: Cable, 2.00 m, PUR, Switching output: NPN normally open (NO), Switching frequency: 100 Hz, Range: 5.4...6.6 mm, Housing material: 1.4301 stainless steel, Material sensing surface: PTFE, Ambient temperature: -30...70 °C, Operating voltage Ub: 12...30 VDC, Approval/Conformity: CE, cULus, EAC, WEEE, IP rating: IP64
Series
D22
Installation
for flush mounting
Connection
Cable, 2.00 m, PUR
Switching output
NPN normally open (NO)
Switching frequency
100 Hz
Range
5.4...6.6 mm
Housing material
1.4301 stainless steel
Material sensing surface
PTFE
Ambient temperature
-30...70 °C
Operating voltage Ub
12...30 VDC
Approval/Conformity
CEcULusEACWEEE
IP rating
IP64
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity | (All languages)
Taric code
85365019
