Balluff
BCC VB63-M423-3E-667-VX8350-006
Soovitatav asendus:
Hind käibemaksuta
Küsi pakkumist
BCC06EH (BCC VB63-M423-3E-667-VX8350-006) - Double-ended cordsets - Connection 1: B, Ind.-180°-Female, angled, 3-pin, Connection 2: M12x1-Male, angled, 3-pin, A-coded, Cable: PVC gray, 0.6 m, Number of conductors: 3, Cable temperature, fixed routing: -40...105 °C, Cable temperature, flexible routing: 5...105 °C, Operating voltage Ub: 60 VDC / 60 VAC, Rated current (40 °C): 4.0 A, IP rating: IP67/IP67, IP69K, Approval/Conformity: CE, WEEE
Connection 1
B, Ind.-180°-Female, angled, 3-pin
Connection 2
M12x1-Male, angled, 3-pin, A-coded
Cable
PVC gray, 0.6 m
Number of conductors
3
Cable temperature, fixed routing
-40...105 °C
Cable temperature, flexible routing
5...105 °C
Operating voltage Ub
60 VDC / 60 VAC
Rated current (40 °C)
4.0 A
IP rating
IP67/IP67, IP69K
Approval/Conformity
CEWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity | (All languages)
Taric code
85444290
Disposal instructions
Download
Juhendid, CAD-mudelid, sertifikaadid ja muud materjalid on tootja veebisaidil:
Ava toote leht tootja veebisaidil
