BCC0A7T (BCC M455-0000-1B-RN038-020) - Receptacles - Connection: M12x1-Female, straight, 2-pin, B-coded, Number of conductors: 2, Conductor cross-section: 22 AWG, Operating voltage Ub: 300 VDC / 300 VAC, Rated current (40 °C): 4.0 A, IP rating: IP67, Cable temperature, fixed routing: -40...105 °C, Approval/Conformity: cULus, EAC, WEEE
Connection
M12x1-Female, straight, 2-pin, B-coded
Number of conductors
2
Conductor cross-section
22 AWG
Operating voltage Ub
300 VDC / 300 VAC
Rated current (40 °C)
4.0 A
IP rating
IP67
Cable temperature, fixed routing
-40...105 °C
Approval/Conformity
cULusEACWEEE
Manufacturer
Balluff GmbH
Taric code
85444290
