BCC0P9C (BCC M415-M415-3L-RM152-000) - Bulkheads - List price Deutschland: 53,28 EUR - Connection 1: M12x1-Female, straight, 5-pin, L-coded-coded, Connection 2: M12x1-Male, straight, 5-pin, L-coded-coded, Mounting part: M16x1.5, Operating voltage Ub: 63 VAC, Rated current (40 °C): 16.0 A, IP rating: IP67/IP67, Ambient temperature: -40...85 °C, Approval/Conformity: WEEE, cURus, CE, UKCA
Connection 1
M12x1-Female, straight, 5-pin, L-coded-coded
Connection 2
M12x1-Male, straight, 5-pin, L-coded-coded
Mounting part
M16x1.5
Operating voltage Ub
63 VAC
Rated current (40 °C)
16.0 A
IP rating
IP67/IP67
Ambient temperature
-40...85 °C
Approval/Conformity
WEEEcURusCEUKCA
Manufacturer
Balluff GmbH
Taric code
85444290
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
