BCC0J4U (BCC M415-M413-3B-301-PS0350-050) - Double-ended cordsets - List price Deutschland: 52,10 EUR - Connection 1: M12x1-Female, straight, 5-pin, B-coded, Connection 2: M12x1-Male, straight, 3-pin, B-coded, Cable: PUR Shielded black, 5 m, Number of conductors: 3, Cable temperature, fixed routing: -40...80 °C, Cable temperature, flexible routing: 0...80 °C, Operating voltage Ub: 60 VDC / 60 VAC, Rated current (40 °C): 4.0 A, IP rating: IP67/IP67, Approval/Conformity: CE, WEEE, cULus
Connection 1
M12x1-Female, straight, 5-pin, B-coded
Connection 2
M12x1-Male, straight, 3-pin, B-coded
Cable
PUR Shielded black, 5 m
Number of conductors
3
Cable temperature, fixed routing
-40...80 °C
Cable temperature, flexible routing
0...80 °C
Operating voltage Ub
60 VDC / 60 VAC
Rated current (40 °C)
4.0 A
IP rating
IP67/IP67
Approval/Conformity
CEWEEEcULus
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity | (All languages)
Taric code
85444290
Substances of concern
Download
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
