BCC0P77 (BCC M414-M414-M414-T0134-000) - Tees - List price Deutschland: 112,42 EUR - Connection 1: M12, 4-pin, S-coded, Connection 2: Female, 4-pin, S-coded, Connection 3: Female, 4-pin, S-coded, Operating voltage Ub: 630 VAC, Rated current (40 °C): 12.0 A, IP rating: IP65, IP67, IP68, installed, Ambient temperature: -30...90 °C, Approval/Conformity: CE, UKCA, cULus, WEEE
Connection 1
M12, 4-pin, S-coded
Connection 2
Female, 4-pin, S-coded
Connection 3
Female, 4-pin, S-coded
Operating voltage Ub
630 VAC
Rated current (40 °C)
12.0 A
IP rating
IP65, IP67, IP68, installed
Ambient temperature
-30...90 °C
Approval/Conformity
CEUKCAcULusWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity | (All languages)
Taric code
85366990
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
