BCC0FK4 (BCC A345-0000-20-000-51X5A5-000) - Field attachables - List price Deutschland: 29,34 EUR - Connection: 7/8"-16 UN-Male, angled, 5-pin, Number of connectable contacts: 5, Connection cross-section: 0.75...1.5 mm², Type of wire mounting: Screw terminals, Cable diameter D: 6...8 mm, Operating voltage Ub: 600 VDC / 600 VAC, Rated current (40 °C): 9.0 A, IP rating: IP67, Ambient temperature: -25...85 °C, Approval/Conformity: CE, cURus, WEEE
Connection
7/8"-16 UN-Male, angled, 5-pin
Number of connectable contacts
5
Connection cross-section
0.75...1.5 mm²
Type of wire mounting
Screw terminals
Cable diameter D
6...8 mm
Operating voltage Ub
600 VDC / 600 VAC
Rated current (40 °C)
9.0 A
IP rating
IP67
Ambient temperature
-25...85 °C
Approval/Conformity
CEcURusWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Taric code
85366990
Substances of concern
Download
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
