BCC0JCM (BCC A335-0000-20-000-G3X5A5-000) - Field attachables - List price Deutschland: 47,32 EUR - Connection: 7/8"-16 UN2A-Male, straight, 5-pin, Number of connectable contacts: 5, Connection cross-section: 0.75...1.5 mm², Type of wire mounting: IDC, Cable diameter D: 6.8...12.5 mm, Operating voltage Ub: 230 VDC / 230 VAC, Rated current (40 °C): 10.0 A, IP rating: IP67, IP65, Ambient temperature: -40...85 °C, Approval/Conformity: WEEE
Connection
7/8"-16 UN2A-Male, straight, 5-pin
Number of connectable contacts
5
Connection cross-section
0.75...1.5 mm²
Type of wire mounting
IDC
Cable diameter D
6.8...12.5 mm
Operating voltage Ub
230 VDC / 230 VAC
Rated current (40 °C)
10.0 A
IP rating
IP67, IP65
Ambient temperature
-40...85 °C
Approval/Conformity
WEEE
Manufacturer
Balluff GmbH
Manual
BCC A335-000-x0-000-G3X5A5 | (German, English)
Taric code
85366990
Substances of concern
Download
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
