Balluff
BAV BP-PH-00015-03
Recommended replacements:
- BCC03P3 BCC M415-M313-3F-300-VX8334-050
- BCC02W0 BCC M313-M313-30-300-VX8334-050
- BCC02NL BCC M313-0000-20-001-VX8334-020
- BCC02NN BCC M313-0000-20-001-VX8334-100
- BCC0A7A BCC VA04-M313-30-682-VX8350-030
- BCC02UT BCC M313-M313-30-300-VX8334-006
- BCC02UU BCC M313-M313-30-300-VX8334-010
- BCC02UY BCC M313-M313-30-300-VX8334-020
- BCC03P0 BCC M415-M313-3F-300-VX8334-015
- BCC03HA BCC M323-M413-3E-602-PX0334-030
- BCC06J8 BCC A314-A324-30-304-PX04A5-020
Price excluding VAT
Request a quote
SET01CW (BAV BP-PH-00015-03) - Double-ended cordsets -
Connection 1
M12x1-Female, straight, 5-pin, A-coded
Connection 2
M8x1-Male, straight, 3-pin, A-coded
Cable
PVC gray, 5 m, drag chain compatible
Number of conductors
3
Cable temperature, fixed routing
-40...105 °C
Cable temperature, flexible routing
5...105 °C
Operating voltage Ub
60 VDC / 60 VAC
Rated current (40 °C)
4.0 A
IP rating
IP67, IP68, IP69K/IP67, IP69K
Approval/Conformity
CEcULusWEEE
Connection
M8x1-Male, straight, 3-pin, A-coded
Conductor cross-section
0.34 mm²
Function indicator
Yellow LED/No
Suppressor
Suppressor diode
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
