8 pairs of solder pins screw terminals connected to solder pin pairs
Weight
0,086 kg
Country of origin
CZ
Model designation
MKS - M 8
Operating voltage AC max.
50 V
Operating voltage DC max.
75 V
Operating current max.
5 A
Flame resistance
flame retardant
Material housing
Plastic
Housing properties
removable cover
Height
68 mm
Width
45 mm
Depth
62 mm
Mounting method
geschnappt
Suitable for mounting type
Mounting rail TH35, (EN 60715), G32
Distance of solder pins
40 mm
