Murrelektronik
Adaptor M8 male / M12 female A-cod. Lite
Price excluding VAT
Request a quote
Adapter Male - female M8 – M12, 3-pole for M8 distribution box 3-pole 7005 - plastic hexagonal screw (M12/M8 Lite)
Weight
0,012 kg
Country of origin
DE
Model designation
MSB04L0-H-R-S05
Family construction form
M12
Threaded hole
M12 x 1
Tightening torque
0,6 Nm
Width across flats
SW13
Operating voltage AC max.
50 V
Operating voltage DC max.
60 V
Current operating per contact max.
4 A
Operating voltage AC max. (UL-listed)
30 V
Operating voltage DC max. (UL-listed)
30 V
Degree of protection (EN IEC 60529)
IP67
Additional condition protection degree
mounted, screwed
Pollution Degree
3
