Ethernet CAT5 Control cabinet entry system Female straight – female 90° M12 – RJ45, 4-pole D-coded Shielded suitable for sheet thickness 2.0...5.0 mm...
Kaal
0,040 kg
Päritoluriik
CZ
Mudeli tähistus
M12-RJ45-Ethernet-Adapter gew.4pol
Family construction form
RJ45
No. of poles
4
Coding
D
Gender
female
Mounting method
pluggable
Degree of protection (EN IEC 60529)
IP20
Operating voltage DC max.
60 V
Current operating per contact max.
1,76 A
Data transmission rate max.
100 Mbit/s
Transfer parameters
CAT5, Class D (ISO/IEC 11801:2002), (EN 50173-1)
duplex
Full duplex
Material housing
PUR
