A3 Female 3-pole Screw terminal Technical data will be only guaranteed with Murrelektronik components.
Вес
0,015 kg
Страна происхождения
CZ
Обозначение модели
MSMH-EBU-A03-S-3pol. 400 V 10 A
Operating voltage AC
400 V
Operating voltage DC
400 V
Operating current
10 A
Connection cross section min.
0,5 mm²
Connection cross section max.
1,5 mm²
Gender
female
Connection
Screw terminals SK
Tightening torque clamping screw
0,2 Nm
Mating cycles min.
500
Stripping length
5 mm
Wire insulation diameter min.
4 mm
No. of poles
3 + PE
