MST SINGLE-PHASE SAFETY TRANSFORMER

SKU: 866178 Available to order
Price excluding VAT
Request a quote

Request a quote

    Single-phase - Control and Isolation Transformers 100 VA Isolation class T 40/B Other voltages on request.

    Weight
    2,000 kg
    Country of origin
    CZ
    Model designation
    MST 0100-230/20
    Power frequency
    50 ... 60 Hz
    Input voltage AC
    230 V
    Nominal input voltage AC
    230 V
    Current input AC
    0,52 A
    Nominal current AC
    230 V
    Max. inrush current
    5 A
    Short-circuit current
    7 A
    Output voltage adjustable
    No
    Output voltage AC
    20 V
    Power rating AC max.
    100 VA
    Insulation test voltage input - output
    3,8 kV
    Height
    88 mm
