Male straight 7/8" (5-pole) IDC terminals Connection cross section: 0.75...1.5 mm² Stainless steel 1.4305 (V2A) Plastic housings with good resistance...
Weight
0,104 kg
Country of origin
DE
Model designation
7/8''St.ger.5p.MOSA 0,75-1,5qmm V2A
Current operating per contact max.
10 A
Current phase - neutral
230 V
Current phase - phase
400 V
Single wire diameter min.
0,15 mm
Connection cross section min.
0,75 mm²
Connection cross section max.
1,5 mm²
Tightening torque
1,5 Nm
Mounting set
7/8"
Wire insulation diameter max.
2,8 mm
Coding
A
No. of poles
5
Degree of protection (EN IEC 60529)
IP67, IP65
